SunnySky XS High Power X4110S 400kv Fırçasız Motor
2.200,00 TL + KDV
Stok Kodu
J6EA2BU795
Fiyat
2.200,00 TL + KDV
KDV Dahil Fiyat
2.640,00 TL
| No.of Stator Slots | 12 | Rotor Diameter | 47.5mm |
|---|---|---|---|
| No.of Rotor Poles | 14 | Shaft Diameter | 4mm |
| Motor Kv | 400 | Body Length(without shaft) | 32mm |
| No-load current | 0.6A/10V | Body Length | 37.5mm |
| Motor Resistance | 107mΩ | Max Lipo Cell | 6S |
| Max Continuous Current | 45A/30s | ESC | 40-60A |
| Max Continuous Power | 1125W | Recommended Prop(inch) | 15*5.5/16*6/18*6.1/17*5.8 |
| Weight | 165g |
| Prop(inch) | Voltage(V) | Amps(A) | Thrust(gf) | Watts(W) | Efficiency(g/W) | Load temperature in 100% throttle |
|---|---|---|---|---|---|---|
| 15*5.5 | 22.2 | 1.9 | 500 | 42 | 11.85 | 53℃ |
| 3.2 | 750 | 71 | 10.56 | |||
| 4.9 | 1000 | 109 | 9.19 | |||
| 6.9 | 1250 | 153 | 8.16 | |||
| 9.2 | 1500 | 204 | 7.34 | |||
| 11.4 | 1750 | 253 | 6.91 | |||
| 14.2 | 2000 | 315 | 6.34 | |||
| 18.8 | 2430 | 417 | 5.82 | |||
| 25 | 1.7 | 500 | 43 | 11.76 | ||
| 2.9 | 750 | 73 | 10.34 | |||
| 4.4 | 1000 | 110 | 9.09 | |||
| 6.1 | 1250 | 153 | 8.2 | |||
| 7.9 | 1500 | 198 | 7.59 | |||
| 9.9 | 1750 | 248 | 7.07 | |||
| 12.5 | 2000 | 313 | 6.4 | |||
| 15.6 | 2300 | 390 | 5.9 | |||
| 18.8 | 2600 | 470 | 5.53 | |||
| 22.3 | 2840 | 558 | 5.09 | |||
| 16*6 | 22.2 | 2 | 500 | 44 | 11.26 | 65℃ |
| 3.5 | 750 | 78 | 9.65 | |||
| 5.1 | 1000 | 113 | 8.83 | |||
| 7 | 1250 | 155 | 8.04 | |||
| 9.3 | 1500 | 206 | 7.27 | |||
| 11.5 | 1750 | 255 | 6.85 | |||
| 14.1 | 2000 | 313 | 6.39 | |||
| 17.7 | 2300 | 393 | 5.85 | |||
| 21.8 | 2600 | 484 | 5.37 | |||
| 26.6 | 2930 | 591 | 4.96 | |||
| 25 | 1.7 | 500 | 43 | 11.76 | ||
| 3.1 | 750 | 78 | 9.68 | |||
| 4.6 | 1000 | 115 | 8.7 | |||
| 6.2 | 1250 | 155 | 8.06 | |||
| 8.3 | 1500 | 208 | 7.23 | |||
| 10.4 | 1750 | 260 | 6.73 | |||
| 12.8 | 2000 | 320 | 6.25 | |||
| 26 | 2300 | 650 | 3.54 | |||
| 19.5 | 2600 | 488 | 5.33 | |||
| 25.4 | 3000 | 635 | 4.72 | |||
| 31.7 | 3400 | 793 | 4.29 | |||
| 17*5.8 | 22.2 | 1.6 | 500 | 36 | 14.08 | 75℃ |
| 2.9 | 750 | 64 | 11.65 | |||
| 4.4 | 1000 | 98 | 10.24 | |||
| 6.1 | 1250 | 135 | 9.23 | |||
| 8.1 | 1500 | 180 | 8.34 | |||
| 10.3 | 1750 | 229 | 7.65 | |||
| 13.1 | 2000 | 291 | 6.88 | |||
| 16.4 | 2300 | 364 | 6.32 | |||
| 19.9 | 2600 | 442 | 5.89 | |||
| 27.7 | 3130 | 615 | 5.09 | |||
| 25 | 1.4 | 500 | 35 | 14.29 | ||
| 2.5 | 750 | 63 | 12 | |||
| 3.9 | 1000 | 98 | 10.26 | |||
| 5.4 | 1250 | 135 | 9.26 | |||
| 7.2 | 1500 | 180 | 8.33 | |||
| 9.3 | 1750 | 233 | 7.53 | |||
| 11.4 | 2000 | 285 | 7.02 | |||
| 13.7 | 2300 | 343 | 6.72 | |||
| 18.4 | 2600 | 460 | 5.65 | |||
| 23.3 | 3000 | 583 | 5.15 | |||
| 33.3 | 3600 | 833 | 4.32 | |||
| 18*6.1 | 22.2 | 1.6 | 500 | 36 | 14.08 | 83℃ |
| 2.8 | 750 | 62 | 12.07 | |||
| 4.4 | 1000 | 98 | 10.24 | |||
| 6.1 | 1250 | 135 | 9.23 | |||
| 8.6 | 1500 | 191 | 7.86 | |||
| 9.9 | 1750 | 220 | 7.96 | |||
| 13.1 | 2000 | 291 | 6.88 | |||
| 16.6 | 2300 | 369 | 6.24 | |||
| 20.7 | 2600 | 460 | 5.66 | |||
| 32.2 | 3300 | 715 | 4.62 | |||
| 25 | 1.5 | 500 | 38 | 13.33 | ||
| 2.5 | 750 | 63 | 12 | |||
| 3.9 | 1000 | 98 | 10.26 | |||
| 5.4 | 1250 | 135 | 9.26 | |||
| 7.4 | 1500 | 185 | 8.11 | |||
| 9.4 | 1750 | 235 | 7.45 | |||
| 11.7 | 2000 | 293 | 6.84 | |||
| 14.5 | 2300 | 363 | 6.34 | |||
| 18.8 | 2600 | 470 | 5.53 | |||
| 24.3 | 3000 | 608 | 4.94 | |||
| 34.6 | 3500 | 865 | 4.05 | |||
| 38.4 | 3720 | 960 | 3.88 |
